Week 08 Β· Bounce, Roll and Stop

Monday

The missing height
// Where the energy goes
⏱ about 20 min

Monday: The Missing Height

Rocket holds a tennis ball at shoulder height above a patio tile and lets it drop.

It bounces back up to about his knee. Raven holds the tape measure upright beside the bounce.

"It came back lower," Rocket says. "Every time. Where did the rest of the height go?"

Raven writes the two numbers. "What do you notice? It never comes back to your hand. Not even close."

Nova hovers level with the top of the bounce. "Energy does not disappear," she says. "So something else must have changed."

Rocket presses his palm flat on the tile where the ball landed. "Warmer? I cannot feel it."

"Too small to feel," Raven says. "But you heard the thump. Sound is energy too."

Nova hums. "You just found the week's rule."

Rocket drops a tennis ball onto a patio tile and it bounces back up to about his knee. Raven holds a tape measure upright beside the bounce with a notebook under her arm. Nova hovers level with the top of the bounce, glowing cyan. A rug and a wooden board lie nearby for the next test.

Energy is never lost

A physics text states the law of conservation of energy. The total energy is constant in any process.

Energy may change in form or be transferred from one system to another, but the total remains the same.

That rule is why the missing height is a puzzle worth solving. The ball had stored energy at your hand. Less came back as height.

The rest did not vanish. It changed form. Some became sound, the thump you heard. Some became thermal energy, a tiny bit of warmth.

The science standards say it this way. When the motion energy of an object changes, there is always some other change in energy at the same time.

MomentWhere the energy is
Ball held at shoulder heightStored as gravitational potential energy
Ball just before it hitsKinetic energy
Ball squashed on the tileElastic energy in the ball, plus some sound and warmth
Ball at the top of the bounceLess potential energy than at the start
The missing partThermal energy in the ball and tile, and sound in the air
WHERE DID IT GO?
  • Read the question.
  • Tap your answer.
The ball bounces back lower than its drop height. What happened to the missing energy?
What does the law of conservation of energy say about the total energy?
You hear a thump when the ball lands. What is the thump?

Thermal energy: warmth is motion too

A physics text explains that atoms and molecules inside all objects are in random motion. This internal energy from random motion is called thermal energy.

Thermal energy is related to the temperature of the object. More random jiggling means warmer.

When the ball squashes against the tile, some of its motion becomes faster jiggling of particles in the ball and tile. They get a tiny bit warmer.

The same text says that when surfaces rub, their atoms vibrate and that energy is converted into heat. That is why rubbing your hands warms them.

The amounts in a bounce are too small to feel, but they are real. Scientists track them with an energy inventory, a list of before and after.

StatementTrue or false?
The total energy stays the same even when it changes form.?
A dropped tennis ball bounces back to exactly its drop height.?
Thermal energy is the random motion of particles inside an object.?
The missing bounce energy was destroyed.?
WHY THIS EXERCISEEvery test this week is a hunt for where the energy went, and the law says it is always somewhere.
Which kind of energy is the random motion of the particles inside a warm object? Type one word.
WHY THIS EXERCISEThermal energy is the usual hiding place for motion energy that seems to vanish.
Try it
Rub your palms together hard for ten seconds. Feel the warmth.
Stop and let them cool. Where did the energy for the warmth come from?
Write "rubbing" and "thermal energy" in your Field Log with your answer.
For a grown-up
This week your student drops a tennis ball onto tile, wood and carpet and measures how high it bounces back.
Drops are from standing reach only. A patio, hallway or kitchen floor works, with a tape measure held against a wall.
The energy facts come from OpenStax physics texts hosted by LibreTexts and from the Next Generation Science Standards.
Draw the ball at the drop height and at the top of the bounce. Between them, draw a small sound wave and a few warm wiggles at the tile.

Strong start. Tomorrow you will follow a bounce and a sliding stop step by step and meet a real bounce number.
