Week 10 Β· Reading the Layers

Monday

Pages in a history book
// Oldest at the bottom, youngest on top
⏱ about 20 min

Monday: Pages in a History Book

Rocket drops a handful of gravel, then sand, then soil into a clear bottle of water and shakes it hard.

"Mud," he announces. "Just mud." He sets it on the Sky Deck step and reaches for the lid.

Raven holds up a hand. "Wait. What do you notice at the bottom?"

The gravel has already landed. Above it, sand is drifting down like slow snow. The water stays brown.

Nova hovers beside the bottle. "A geologist from long ago watched the same thing," she says. "He wrote a rule about it."

"Big stuff first," Rocket says. "Then smaller. Then the tiny bits, maybe never."

Raven writes it down. "Layers. Like pages." Nova hums. "And pages have an order."

Rocket, Raven and Nova at the Sky Deck window. A clear bottle of water with gravel, sand and soil settling into layers sits on the sill. Rocket points at the bottom layer and Raven writes in a notebook. Nova the companion drone hovers beside the bottle with her light on the layers.

Rocks as pages

The United States Geological Survey says we study Earth's history by studying the record preserved in rocks. The layers of the rocks are the pages in our history book.

Most of the rocks exposed at Earth's surface are sedimentary, formed from particles of older rocks broken apart by water or wind.

Gravel, sand and mud settle to the bottom in rivers, lakes and oceans. With time, more particles and chemical changes, the sediments at the bottom of the pile become rock.

Gravel becomes conglomerate. Sand becomes sandstone. Mud becomes mudstone or shale. Animal skeletons and plant pieces can become fossils.

Steno's rule

In the mid-1600s the Danish scientist Nicholas Steno studied how sedimentary rocks sit. He found that solid particles settle from a fluid according to their weight or size.

The largest or heaviest settle first. The smallest or lightest settle last.

Slight changes in particle size or composition make layers, also called beds. Layering, or bedding, is the most obvious feature of sedimentary rocks.

Rock layers are also called strata. Stratigraphy is the science of strata, including how layered rocks relate to time.

Loose sedimentRock it becomesSettles
gravelconglomeratefirst, fastest
sandsandstonenext
mud (silt and clay)mudstone or shalelast, slowest
WHICH SETTLES FIRST?
  • Read the question.
  • Tap your answer.
In still water, which particles settle first according to Steno?
What is the most obvious feature of sedimentary rocks?
Sand that is buried and hardened becomes which rock?
StatementTrue or false?
Most rocks exposed at Earth's surface are sedimentary.?
Mud becomes conglomerate.?
Rock layers are also called strata.?
Steno said the smallest particles settle first.?
WHY THIS EXERCISEKnowing what settles when is the key to reading a stack of layers.
What is another word for rock layers? Type one word.
WHY THIS EXERCISEGeologists say strata, and the word is in the standard you are working toward.
Try it
Find a stack of anything at home: mail, newspapers, folded towels. Which item went on first? How do you know?
Say the rule in your own words: the one on the bottom went on first.
For a grown-up
This week your student shakes sand, soil and gravel in water inside a plastic bottle or jar with a lid. Please tighten the lid yourself and have the shaking happen over a sink or outdoors.
Sand, soil and gravel come from your own yard or a path. Hands are washed afterward and nothing is tasted.
The facts this week come from the United States Geological Survey at pubs.usgs.gov and the open textbook Physical Geology on geo.libretexts.org.
Draw a bottle with three settled layers. Label gravel, sand and mud, and write first, next and last beside them.

Good start. Tomorrow you learn the three rules geologists use to put layers in order.
